DESCRIPTION

Basic Info

Model NO.	ML60
After-sales Service	Installation Guide
Warranty	2 Years
Condition	New
Certification	ISO, CE
Application	Solar System Controller, Charger Controller
Rated Voltage	12V/24V/36V/48V(Adaptive)
OEM	Accepted
Display	LCD Screen
Control Mode	Intelligent Control
Protection	Short Circuit
System Voltage	12V/24V/36V/48V(Adaptive)
Load Voltage	Same as The Battery Voltage
Starting Time	<10s
Charging Mode	MPPT Maximum Power Point Tracking
Applicable Battery Type	Sealed Lead Acid Battery, Gel Lead Acid Battery, O
Nominal Current	60A
Transport Package	Carton Box or Wooden Pallets
Specification	260*219*110mm
Trademark	Techfine
Origin	Foshan, China
HS Code	8537109090
Production Capacity	50000pieces/Year

Packaging & Delivery

Package size per unit product 21.90cm * 26.00cm * 11.00cm Gross weight per unit product 2.800kg

Product Description

Three-stage smart charging
Adjustable parameters by pressing buttons
12V/24V/48V adaptive
Wall mounting

Easy to various paramenters , the operation paramenters are clear to read

High voltage protection
Over load protection
Battery reverse connected protection
Dustproof
Low voltage protection
Overheating protection
Output short-circuit protection
Insect prevention

The maximum utilization rate of solar energy can reach 99%
With super fast charging algorithm, efficiency increased by 30%

Product ParametersProduct detail

Model		40A	60A	80A	100A
System voltage		12V/24V/36V/48V(Adaptive)
Nominal current		40A	60A	80A	100A
Charging mode		MPPT maximum power point tracking
Applicable battery type		Lead acid battery;Gel battery;Flooded battery;Deep cycle battery
Charging method		Four stages: constant current charge, constant voltage charge, floating charge,equalizing charge
PV input maximum open circuit voltage (VOC)		DC150V
System identified voltage	12V	8~16V
	24V	17~30V
	36V	30~42V
	48V	42~64V
PV input voltage	12V	17~150V
	24V	30~150V
	36V	41~150V
	48V	53~150V
Solar panel rated input power	12V	540W	800W	1040W	1300W
	24V	1080W	1600W	2160W	2600W
	36V	1620W	2400W	3240W	3900W
	48V	2160W	3200W	4320W	5200W

Company ProfileFAQ

Q1:May I take some samples to test before placing the order ?

A1:Yes, welcome to take some sample to test!

Q2:How about the delivery time?

A2:7 days for sample; 25 days for bulk order.

Q3:What is the warranty of the controller?

A3:1 years warranty.

Q4:How to solve the technical problems?

A4:24 hours after-service consultancy just for you and to make your problem to be solved

Q5:Do you have any certifications for your products?

A5:We have ISO9001:2000, CE, RoHS, certificates for all of our products.
