DESCRIPTION

Model NO.	2V GEL Batteries
Installation	Packaged
Rechargeable	Chargeable
Maximum Charging	600A
Max. Discharge Current	12000A (5 Sec)
Application	Solar Energy System
Product Name	Lead-Acid Maintenance-Free Battery
Voltage	2 Volt
Capacity	3000ah
Terminal	F10(M8)
Features	Long Cycle Life
Certifcation	CE RoHS ISO9001 ISO14001
Color	Customzied
OEM/ODM	Avaiable
Keyword	Deep Cycle Solar Battery
Transport Package	Carton Package
Specification	Approx. 225.0 Kg (Tolerance +-1%)
Trademark	Sunpal
Origin	China
HS Code	8507200000
Production Capacity	10000000 Per Month

Cells Per Unit	1
Voltage Per Unit	2
Capacity	[email protected] to 1.8V per cell @25°C
Weight	Approx. 225.0 Kg (Tolerancet ±1%)
Internal Resistance	Approx. 0.35 mΩ
Terminal	F10(M8)
Max. Discharge Current	12000A (5 sec)
Design Life	20 years (floating charge)
Maximum Charging Current	600.0A
Reference Capacity	C24 3180AHC48 3279AH C72 3690AH C100 3750AH C120 3816AH C240 3881AH
Float Charging Voltage	3.25 V~2.3 V @ 25°ºCTemperature Compensation: -3mV/C/Cell
Cycle Use Voltage	2.37V~2.4 V @ 25°Temperature Compensation: -4mV/C/Cell
Operating Temperature Range	Discharge: -40°C~60ºCCharge: -20ºC~50ºCStorage: -40C~60ºC
Normal Operating Temperature Range	25°ºC±5ºC
Self Discharge	Less than 2% at 25°C per month
Container Material	A.B.S. UL94-HB, UL94-VO Optional.
