Blue MPPT100/30 Solar Charge Controller MPPT 30A 12V 24V

Send your inquiry

DESCRIPTION

Open Circuit Voltage Solar Module ( at M	100V
Charge Current	30A
Ambient Temperature	-30.....+60 Degree
Weight	1300 G
Dimensions (X X Y X Z)	130 X 186 X 70 mm
Charge Voltage Absorption	Default Setting: 14.4V/28.8V
Protection Category	IP43
Transport Package	Standard Export Carton Packing
Specification	CE, RoHs, SGS, ISO9001
Trademark	Fangpusun
Origin	Zhejiang, China
HS Code	8537109090
Production Capacity	50000PCS Per Year

Fangpusun solar charge controller		MPPT100/30	MPPT100/50
System voltage		12v/24v Auto Select
Maximum output current		30A	50A
Maximum PV power, 12V 1a,b)		440W (MPPT range 15V to 80V)	700W (MPPT range 15V to 70V resp.95V)
Maximum PV power, 24V 1a,b)		880W (MPPT range 30V to 80V)	1400W (MPPT range 30V to 70V resp.95V)
Maximum PV open circuit voltage		100V
Maximum efficiency		98%
Self-consumption		10mA
Charge voltage absorption		14.4 V/ 28.8V (adjustable)
Charge voltage float		13.8 V/ 27.6V (adjustable)
Charge algorithm		Multi-stage adaptive
Temperature compensation		-16mV / resp.-32mV/
Protection		Battery reverse polarity (fuse) Output short circuit / Over temperature
Operating temperature		-30 to +60 (full rated output up to 40)
Humidity		95%, non-condensing
ENCLOSURE
Colour	Blue. Orange. Black
Power terminals	13mm/AWG6
Protection category	IP43 (electronic components), IP22 (connection area)
Weight	1.5kg
Dimensions (H x W x D)	13018670mm
STANDARDS
Safety	EN/IEC 62109
