MPPT Solar Charge Controller 80AMP 12/24/36/48V Charger Controller for Home Use Solar Panel System Controller

MPPT Solar Charge Controller 80AMP 12/24/36/48V Charger Controller for Home Use Solar Panel System Controller

Overview Product Description Product Parameters PackingCertificationsCompany ProfileFAQ FAQQ1: Does your company also pr

Send your inquiry

DESCRIPTION

Basic Info
Model NO. MP
Accessories Charger Adapter
Supportable Battery Type Gel/SLA/AGM/Water/Lithium(LiFePO4) Battery
Maximum Efficiency More Than 99%
Communication RS485, Available for WiFi Box & External Control
Display LCD+LED Display
Charge Way Three Stage Charging
Transport Package Carton
Specification 4.5KGS
Trademark ONE
Origin China
Production Capacity 100000PCS/ Month
Product Description

MPPT Solar Charge Controller 80AMP 12/24/36/48V Charger Controller for Home Use Solar Panel System Controller

MPPT Solar Charge Controller 80AMP 12/24/36/48V Charger Controller for Home Use Solar Panel System Controller

MPPT Solar Charge Controller 80AMP 12/24/36/48V Charger Controller for Home Use Solar Panel System Controller

MPPT Solar Charge Controller 80AMP 12/24/36/48V Charger Controller for Home Use Solar Panel System Controller

MPPT Solar Charge Controller 80AMP 12/24/36/48V Charger Controller for Home Use Solar Panel System Controller

Product Parameters
ModelMP-30MP-40MP-50MP-60MP-80MP-100MP-120
Rated Current30A40A50A60A80A100A120A
Maximum Charging Current32A42A52A62A82A102A122A
Mppt Range Operating Voltage
12VDC18VDC~80VDC
24VDC30VDC~100VDC
36VDC40VDC~100VDC
48VDC 60VDC~150VDC
96VDC Not Available120VDC~200VDC
Maximum PV Array Power
12VDC280W420W570W900W1140W1400W1800W
24VDC550W840W1130W1700W2260W2800W3400W
36VDC840W1260W1710W2700W3420W4200W5400W
48VDC1100W1650W2270W3400W4540W5600W6800W
96VDC Not Available 7200W9120W11200W14400W
Battery
Supportable Battery TypeGel/SLA/AGM/Water/Lithium(lifepo4) battery
Charging ModeThree Stages: Constand Current(mppt),equalizing Charge, Floating Charge
Maximum Efficiency≥99%
Communication Portal
CommunicationRS485, available for wifi box & external control screen
Packing Details
Dimension,D*W*H(MM)315*235*150360*260*190440*410*200
G.W.(KGS)3.5KGS4.5KGS12KGS
*Product Specifications Are Subject To Change Without Further Notice
PackingCertificationsCompany ProfileFAQ

FAQQ1: Does your company also provide other solar products except Pure Sine Wave Inverter?A1: Yes, we also provide other solar products, like MPPT Solar Controller, poly solar panel, off grid solar inverter, battery, portable solar system, solar charger and other accesoriesrelated to the solar power system.Q2: How to choose a right inverter?A2: Tell us your demand, then our sales will recommend a suitable inverter to you.
Q3: How about the delivery time?A3: 5 days for sample; 7-15 days for bulk order.Q4: What is the warranty of inverter?A4: 1 year warranty.Q5: How to solve the technical problem?A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
